Features

• Soft seat replaceable valve operates in dirty service with repetitive bubble-tight shutoff.
• Packing below threads prevents lubricant washout, thread corrosion, process contamination and eliminates galling.
• Easily adjustable PTFE packing decreases replacement downtime and increases valve life.
• Dust cover protects stem from lubricant contamination.
• Safety back seating prevents stem blowout or accidental removal and provides a metal-to-metal secondary stem seal while in the fully open position.
• ENC plated 316 SS stem prevents galling or freezing of stem threads. CS valves use a 303 SS stem for 'hard-to-soft' contact, to prevent galling.
• Rolled stem and bonnet threads provide additional strength.
• Mirror stem finish in the packing area provides smooth operation and extends packing life.
• Straight-through flow path means high flow capacity, bi-directional flow and rodding capabilities.
• Metal-to-metal body-to-bonnet seal in constant compression prevents bonnet thread corrosion, eliminates possible tensile
