100NB CL150 R/F BLIND FLANGE BORED TO SUIT 101.6 OD TUBE ASTM A182 F316L

Item Code: ASA100X100TBLRFB
Delivery date: 1-2 days
100NB (4") CL150 RAISED FACE BLIND FLANGE BORED TO SUIT 101.6 OD TUBE ASTM A182 F316L
Product Files
Flanges
Products specifications
Material / GradeSS316/316L
Nominal Bore100NB (4")
Piping ClassCL150
TypeTUBE SLIP ON FLANGE
Number of Bolt Holes8
Diameter of Bolt Holes19.1 mm
Tube OD101.6 (4")

Attachments
